Automatic Sewing Machine for Very Thin Heating Wire Changeable Heating Design on Pad

2.

Sewing Area

X(Lateral) Direction Y(Longitudinal) Direction
600(mm) x 400(mm) (customizable)

3.

Max. Sewing Speed

2000 RPM

4.

Stitch length

0.1-5.0mm(resolution capacity 0.1mm)

5.

Function device

Fast mould, high-low presser foot/special thread clamper

6.

System

Self-developed control system

7.

Speed set

200-1500rpm, 10 sections set

8.

Thread pendulum radian

0-10mm

9.

Maximum stitch amount

Needles/1 pattern

10.

Rising amount of outer presser foot

32mm

11.

Rising amount of inner presser foot

20mm

12.

Stroke by inner presser foot

4-10mm

13.

Presser foot drive method

Pendulum type

14.

Pattern memory

Internal storage(999 patterns), U disk

15.

Hook

2 times of rotating hook（HIROSE）

16.

Valve

Airtac

17.

Guide rail

TBI

18.

Belt

ALPNA

19.

Needle

DP*17*18

20.

Spindle motor

750W

21.

Operation Temperature Range

0℃～45℃

22.

Operation Humidity Range

35%～85% （No Dew Condensation）

23.

Line Voltage

AC 220V ± 10%；50/60Hz

24.

Machine structure

Automatic winding

25.

Plywood box size

178x144x134cm

26.

Packing volume

3.435cbm

27.

Gross weight

375kg

28.

Application

Electric Heating Pad Mattress Thermal Carpet Blanket, etc.

29.

Certification

CE, RoHS

30.

Language

Chinese, English, Burmese, Korean, Turkish, Japanese, Vietnamese, Italiano, Portuguese, Espanol.

31.

OEM

Yes

32.

Working lasting

24 hours long lasting

33.

HS code

8452219000
